Product Characteristics
Product Flow: 400-600 SCFH (Factory set to your specific requirements.)
Standard Product Pressure: 1–65 psig
Product Purity: 93% Nominal
Product Dew Point: -100°F (-73°C)

Ambient Operating Conditions
Locate the oxygen generator in a well-ventilated area that
is protected from weather elements and remains between
40°F (4°C) and 112°F (44°C)

Feed Air Requirements
Flow Rate: Refer to Chart
Clean and Dry “Plant Air” per ISO Specification 5.7.5
Pressure: 90 psig (620 kPa) minimum
Temperature: 122°F (50°C) maximum

Control Power Requirements
120 V ~ ±10%, 50/60 Hz, Single Phase, 1.5 A
220 V ~ ±10%, 50/60 Hz, Single Phase, 0.75 A
Typical Power Consumption (at 93% purity): 180 W

Physical Characteristics
Dimensions (W x D x H): 79 x 34 x 42 in
Weight: 1870 lb.

Physical Connections
Compressed Air Inlet: ¾” NPT
Product Gas Outlet: 3/8" NPT

Certifications and Approvals
NRTL certified compliance to UL3101.1, CSA, CE Compliant

Warranty: 1 Year Parts and Factory Labor*
*An unprotected or inadequately ventilated environment, improper feed air quality,
or improper control power may cause damage to the oxygen generator not
covered under warranty.
